Product details

$84
SKU: 9781892765437
You can apply the Manual D procedure to constant volume systems and zoned variable air volume systems, over a full range of duct construction materials. Manual D includes a number of informative appendices related to air distribution systems (e.g., equipment and air-side components, controlling excess air when VAV dampers close, duct loads, duct leakage and duct system efficiency, air quality issues, noise control, minimum air velocity for ducts; codes, standards and best practice issues; and commissioning issues).
Back to: Construction

Manual D includes a number of informative appendices related to air distribution systems (e.g., equipment and air-side components, controlling excess air when VAV dampers close, duct loads, duct leakage and duct system efficiency, air quality issues, noise control, minimum air velocity for ducts; codes, standards and best practice issues; and commissioning issues). The Manual D has been significantly revised to include:

  • Updated and expanded VAV guidance, with detailed examples
  • Impacts of excess length, sag and compression in flexible ducts
  • New equivalent length values for flex duct junction boxes

Manual D provides:

  • A single set of ANSI-recognized duct sizing principles and calculations that apply to all duct materials
  • System operating point (supply Cfm and external static pressure), and airway sizing for single-speed and multi-speed (ECM) blowers
  • A method for determining the impact of duct friction and fitting pressure drop on blower performance and air delivery
  • The most comprehensive equivalent length data ever published

You can apply the Manual D procedure to constant volume systems and zoned variable air volume systems, over a full range of duct construction materials. Manual D includes a number of informative appendices related to air distribution systems (e.g., equipment and air-side components, controlling excess air when VAV dampers close, duct loads, duct leakage and duct system efficiency, air quality issues, noise control, minimum air velocity for ducts; codes, standards and best practice issues; and commissioning issues).
